Standard view: Standard display of vital signs parameters.
Big font view: All values are shown in a larger font
ECG waveforms view: 7 traces of ECG waveforms display in phase
Trend coexist view: 5 waveforms and 4 hours’ trends of HR, NIBP, SPO2, RESP and TEMP.
OxyCRG dynamic view: Show SpO2, HR, and RESP in a graphical format.
NIBP view: Show the recent 7 groups of blood pressure data.
8-Inch Touchscreen Patient Monitor
Continuously monitor patient’s vital signs both at the bedside and on transport.
8-Inch Touchscreen Patient Monitor
Continuously monitor patient's vital signs both at the bedside and on transport.
Terms & Conditions
8-Inch Touchscreen Patient Monitor
Continuously monitor patient’s vital signs both at the bedside and on transport.
Advanced features that help comprehensive monitoring
8" Touch Screen
6 Parameters Monitoring
8-Inch Touchscreen
6 Parameters Monitoring
3/5 Leads ECG Waveform Display
15 Kinds of Dose Concentration Calculation
Advanced Features for Comprehensive Monitoring
8-Inch
Touchscreen
6 Parameters Monitoring
Portable
4.37 lbs (1.98 kg), free shoulder bag provided
Pulse Dose Delivery
1-5 flow settings, flexible options for various needs
Advanced Analysis
3/5 Leads ECG Display
High Purity
Consistent 93% ± 3% at all settings
Long-Life Battery
Up to 5.5 hours at the flow setting of 1
Portable
4.37 lbs (1.98 kg), free shoulder bag provided
Pulse Dose Delivery
1-5 flow settings, flexible options for various needs
High Purity
Consistent 93% ± 3% at all settings
Long-Life Battery
Up to 5.5 hours at the flow setting of 1
Quiet
Around 38 dB (equivalent to refrigerator humming)
Plateau Travel
Altitude above 13,000 feet (4,000 meters)
15 Kinds of Dose Concentration Calculation
For All Kinds of Workplace
Intelligent Alarm
Alarm for power failure, low O2 levels, no breath and etc.
Long-term Warranty
3-year warranty on the main unit
Quiet
Around 38 dB (equivalent to refrigerator humming)
Plateau Travel
Altitude above 13,000 feet (4,000 meters)
Intelligent Alarm
Alarm for power failure, low O2 levels, no breath and etc.
Long-term Warranty
3-Year warranty on the main unit
Display A Full Set of Vital Parameters
The 8-inch touchscreen patient monitor can display a full set of vital parameters, including 3-lead/5-lead ECG, respiration, oxygen saturation (SpO2), pulse rate (PR), noninvasive blood pressure (NIBP), temperature and EtCO2 (optional).
Display A Full Set of Vital Parameters
The 8-inch touchscreen patient monitor can display a full set of vital parameters, including 3-lead/5-lead ECG, respiration, oxygen saturation (SpO2), pulse rate (PR), noninvasive blood pressure (NIBP), temperature and EtCO2 (optional).
Intuitive Touch Operation
Equipped with an 8-inch high-resolution touchscreen and an intuitive shortcut menu, this portable patient monitor enhances operational ease and boosts working efficiency.
Multiple Displays to Highlight Different Monitoring Focus
The 8-inch touchscreen patient monitor boasts 6 display views, providing users with various options to visualize and interact with the presented information or content. This hospital patient monitor ensures flexibility and convenience, allowing users to effortlessly switch between different display modes or views based on their preferences or specific requirements.
6 Views to Highlight Different Monitoring Focus
Support standard view, large font view, 7-trace ECG waveforms view, trend coexist view, OxyCRG dynamic view and NIBP view to meet different monitoring needs.
Support 6 display views as below:
6 Views for Different Needs
The vital signs patient monitor supports standard view, large font view, 7-trace ECG waveforms view, trend coexist view, OxyCRG dynamic view and NIBP view to meet different monitoring needs.
13 Types of Arrhythmia Analysis
The portable patient monitor can conduct up to 13 different arrhythmia analyses and store the latest 60 alarm events in a dedicated buffer. This function can call the doctor's attention to the patient's heart rate by measuring and classifying the arrhythmia and abnormal heartbeat and triggering the alarm. Additionally, users can edit these arrhythmia events through the menu for further customization.
Which arrhythmia analyses are supported?
- TACHY: Tachycardia
- BRADY: Bradycardia
- MISSED BEATS
- PN: Pacemaker not captured
- PNP: Pacemaker is not pacing
- ASYSTOLE
- VFIB/VTAC: Ventricular fibrillation/ventricular tachycardia
- R ON T
- VT> 2
- COUPET
- PVC
- BIGEMINY
- TRIGEMINY
13 Types of Arrhythmic Analysis
The monitor is capable of conducting up to 13 different arrhythmia analyses and storing the latest 60 alarm events in a dedicated buffer. This function can call the doctor's attention to the patient's heart rate by measuring and classifying the arrhythmia and abnormal heartbeat and triggering the alarm. Additionally, users can edit these arrhythmia events through the menu for further customization.
Which arrhythmia analyses are supported?
- TACHY: Tachycardia
- BRADY: Bradycardia
- MISSED BEATS
- PN: Pacemaker not captured
- PNP: Pacemaker is not pacing
- ASYSTOLE
- VFIB/VTAC: Ventricular fibrillation/ventricular tachycardia
- R ON T
- VT> 2
- COUPET
- PVC
- BIGEMINY
- TRIGEMINY
13 Types of Arrhythmia Analysis
The portable patient monitor can conduct up to 13 different arrhythmia analyses and store the latest 60 alarm events in a dedicated buffer. This function can call the doctor's attention to the patient's heart rate by measuring and classifying the arrhythmia and abnormal heartbeat and triggering the alarm. Additionally, users can edit these arrhythmia events through the menu for further customization.
Which arrhythmia analyses are supported?
- TACHY: Tachycardia
- BRADY: Bradycardia
- MISSED BEATS
- PN: Pacemaker not captured
- PNP: Pacemaker is not pacing
- ASYSTOLE
- VFIB/VTAC: Ventricular fibrillation/ventricular tachycardia
- R ON T
- VT> 2
- COUPET
- PVC
- BIGEMINY
- TRIGEMINY
Real-Time ST Segment Analysis
It is available to measure the variance of the ST segment through ST analysis on selected lead waveform tracks. The corresponding ST measurement result displays numerically at ST1 and ST2 in the parameter area. The trend can be viewed in table or graphic form.
15 Kinds of Dose Concentration Calculation
Healthcare professionals can easily assess and monitor the concentration levels of 15 different doses with the calculation function. This feature empowers clinicians to ensure safe and effective patient care during anesthesia.
Real-time Printing via Ethernet Cable
Supports patient data printing by connecting to a network printer via an Ethernet cable, allowing healthcare professionals to promptly archive and organize patient data.
Optional End-Tidal CO2 Monitoring
End-tidal CO2 monitoring plays a vital role in clinical practice by providing real-time information about a patient's respiratory and circulatory status. It assists healthcare providers in assessing and managing patients' vital signs to deliver better medical care.
Optional End-Tidal CO2 Monitoring
End-tidal CO2 monitoring plays a vital role in clinical practice by providing real-time information about patient's respiratory and circulatory status. It assists healthcare providers in assessing and managing patients' vital signs to deliver better medical care.
SideStream EtCO2 Modules
SideStream EtCO2 Module
Related Articles
Compatible with Adults And Children
Apply for Adults and Children
The touchscreen patient monitor is suitable for use with adults, children and newborns usage in diverse healthcare environments. We also offer additional accessories for pediatric patients for purchase.
Apply in A Variety of Settings
Ward Care
Ambulance (On-Transport)
Community Care
Home Health Care
Apply in A Variety of Settings
Ward Care
On-Transport
Community Care
Home Health Care
More Advanced Features
for All Acute Care Environments
More Features for All Acute Care Environments
Trend Coexist Display & OxyCRG DyNamic View Display
To help healthcare providers better understand the patient's condition and trend changes.
Anti-ESU & Anti-Defibrillator
It can be used in various harsh environments such as surgery and wards.
Built-in Rechargeable Battery
Can support up to 4 hours of continuous working.
Anti-ESU & Anti-Defibrillator
Classified into three categories, which are physiological alarm, technical alarm
and general alarm.
What's In the Box
8-Inch Portable Patient Monitor
Metal Back Rack
5 Leads ECG Cable
NIBP Cuff for Adult (buy large size cuff)
NIBP Extendsion Tube
Disaposable Electrodes 10 pcs (come with package)
SpO2 Finger Probe for Adult
TEMP Probe
Power Adaptor x 2 (used in all countries)
User Manual
If you want more accessories for neonatal patients, please contact us at support@getwellue.com
Accessories in the Package
Included in the package, we provide all the accessories you need to operate the unit.
1 Set of patient ECG cable
NIBP cuff for adult
(27-35cm)
NIBP extendsion tube
SpO2 sensor for adult
In Case You Need More
Accessories for Pediatric Patients
Compatible with Rolling Stand
What's In the Box
8-Inch Patient Monitor
Metal Back Rack
5 Leads ECG Cable
NIBP Cuff for Adult (buy large size cuff)
NIBP Extendsion Tube
Disaposable Electrodes 10 pcs (come with package)
SpO2 Finger Probe for Adult
TEMP Probe
Power Adaptor x 2 (used in all countries)
User Manual
Accessories in the Package
Included in the package, we provide all the accessories you need to operate the unit.
1 set of patient ECG cable
NIBP cuff
NIBP extendsion tube
SpO2 finger probe for adult
In Case You Need More
Accessories for Pediatric Patients
Accessories in the Package
Included in the package, we provide all the accessories you need to operate the unit.
In Case You Need More
Compatible with Rolling Stand
Accessories for Pediatric Patients
Technical Specifications
- PHYSICAL DETAILS
- ECG
- NIBP
- RESP
- SPO2
- TEMP
Size
6.9"*8.3"*3.1"
Weight
2.9lb
Display
8" color touchscreen
Power
Input: AC 90 V~240V, 50/60Hz
Output: DC 12V ~ 20V
Battery capacity: 2200mAh
Type of Battery
Built-in rechargeable lithium battery
Type of EtCO2 Sensor
SideStream
Life of Main Unit & EtCO2 Sensor
5 years
Warranry
1 year
Admin Password
5188
Demo/User Key
2016
Menu Language
English/Chinese/French/Russian/Turkish/Spanish/Portuguese
Lead Mode
5 Leads or 3 Leads
5 Leads ( R, L, F, N, C or RA, LA, LL, RL,V)
Lead selection: I, II, III, avR, avL, avF, V,
Waveform: 3 ch
3 Leads ( R, L, F or RA, LA, LL)
Lead selection: I, II, III,
Waveform: 1 ch
Gain
x2.5mm/mV, x5.0mm/mV, x10mm/mV, x20mm/mV, auto
HR and Alarm
Range: Adult: 15-300 bpm, Neonate/Pediatric: 15-350 bpm
Accuracy: ± 1% or ± 1bpm, which great
Resolution: 1 bpm
Sensitivity: > 200 (uV P-P)
Differential Input Impedance
> 5 MΩ
CMRR
Monitor: > 105 dB, Operation: > 105 dB, Diagnosis: > 85 dB
Electrode Offset Potential
±300mV
Leakage Current
< 10 uA
Baseline Recovery
< 3s after defi
ECG Signal Range
±8mV (Vp-p)
Bandwidth
Surgery: 1-15 Hz, Monitor: 0.5-35 Hz, Diagnostic: 0.05-100 Hz
Calibration Signal
1 (mV p-p), Accuracy: ±5%
Method
Oscillometric
Mode
Manual, Auto, STAT
Measuring Interval in AUTO Mode
1, 2, 3, 4, 5, 10, 15, 30, 60, 90, 120, 180, 240,480 (Min)
Measuring Period in STAT Mode
5 Min
Pulse Rate Range
40 - 240 bpm
Alarm Type
SYS, DIA, MEAN
Measuring and Alarm Range
Adult Mode: SYS: 40-270 mmHg, DIA: 10-215 mmHg, MEAN: 20-235 mmHg
Pediatric Mode: SYS: 40-200 mmHg, DIA: 10-150 mmHg, MEAN: 20-165 mmHg
Neonatal Mode: SYS: 40-135 mmHg, DIA: 10-100 mmHg, MEAN: 20-110 mmHg
Resolution
Pressure 1mmHg
Accuracy
Maximum Mean error: ±5mmHg
Maximum Standard deviation: ±8mmHg
Overpressure Protection
Adult Mode: 297±3 mmHg
Pediatric Mode: 240±3 mmHg
Neonatal Mode: 147±3 mmHg
Method
Impedance between R-F(RA-LL)
Differential Input Impedance
>2.5 MΩ
Measuring Impedance Range
0.3~5.0 Ω
Base line Impedance Range
0-2.5 KΩ
Bandwidth
0.3 ~ 2.5 Hz
Resp. Rate
Measuring and alarm range: Adult: 0-120 rpm, Neo/Ped: 0-150 rpm
Resolution: 1 rpm
Accuracy: ±22 rpm
Apean alarm: 10-40 S
Measuring Range
0-100 %
Alarm Range
0-100 %
Resolution
1 %
Accuracy
70%-100% ±2 %, 0%-69% unspecified
Actualization interval
about 1 second
Alarm Delay
10 seconds
Pulse Rate
Measuring and Alarm Range: 0-254bpm
Resolution: 1bpm
Accuracy : ±2bpm
Channel
1
Measuring and Alarm Range
0-50℃
Resolution
0.1℃
Accuracy
± 1%℃
Actualization interval
about 1 second
Average Time Constant
<10 seconds
